2016 Ford Escape Standard Equipment
  • Engine: 1.6L EcoBoost -inc: active grille shutters
  • Transmission: 6-Speed Automatic w/SelectShift
  • 3.51 Axle Ratio
  • GVWR: 4,760 lbs
  • Transmission w/SelectShift Sequential Shift Control and Oil Cooler
  • Automatic Full-Time Four-Wheel Drive
  • Battery w/Run Down Protection
  • Gas-Pressurized Shock Absorbers
  • Front And Rear Anti-Roll Bars
  • Electric Power-Assist Speed-Sensing Steering
  • 15.1 Gal. Fuel Tank
  • Quasi-Dual Stainless Steel Exhaust w/Chrome Tailpipe Finisher
  • Permanent Locking Hubs
  • Strut Front Suspension w/Coil Springs
  • Short And Long Arm Rear Suspension w/Coil Springs
  • 4-Wheel Disc Brakes w/4-Wheel ABS, Front Vented Discs, Brake Assist and Hill Hold Control
  • Brake Actuated Limited Slip Differential
  • Wheels: 18″ Sparkle Nickel Painted Aluminum
  • Tires: P235/50R18 A/S -inc: steel mini spare wheel w/mini space-saver spare tire
  • Steel Spare Wheel
  • Compact Spare Tire Mounted Inside Under Cargo
  • Clearcoat Paint
  • Body-Colored Front Bumper w/Metal-Look Rub Strip/Fascia Accent
  • Body-Colored Rear Bumper w/Gray Rub Strip/Fascia Accent and Metal-Look Bumper Insert
  • Gray Bodyside Cladding and Gray Wheel Well Trim
  • Chrome Side Windows Trim
  • Body-Colored Door Handles
  • Body-Colored Power Heated Side Mirrors w/Convex Spotter, Manual Folding and Turn Signal Indicator
  • Fixed Rear Window w/Fixed Interval Wiper, Heated Wiper Park and Defroster
  • Variable Intermittent Wipers
  • Deep Tinted Glass
  • Fully Galvanized Steel Panels
  • Chrome Grille
  • Power Liftgate Rear Cargo Access
  • Tailgate/Rear Door Lock Included w/Power Door Locks
  • Roof Rack Rails Only
  • Fully Automatic Aero-Composite Halogen Headlamps w/Delay-Off
  • Front Fog Lamps
  • Perimeter/Approach Lights
  • Laminated Glass
  • Radio: AM/FM Single CD/MP3 -inc: Sony Audio 10 speakers, HD Radio, speed compensated volume and SiriusXM satellite radio w/6 month prepaid subscription (48 contiguous states/service NOT AVAILABLE in Alaska or Hawaii)
  • Radio w/Seek-Scan, Clock, Steering Wheel Controls, Voice Activation and Radio Data System
  • Integrated Roof Antenna
  • 390w Regular Amplifier
  • SYNC 3 Communications & Entertainment System -inc: enhanced voice recognition, 8″ LCD capacitive touchscreen in center stack w/swipe capability, AppLink, 911 Assist and two smart charging USB ports
  • 2 LCD Monitors In The Front
  • Turn-By-Turn Navigation Directions
  • Driver Seat
  • Passenger Seat
  • Split-Bench Front Facing Manual Reclining Fold Forward Seatback Rear Seat
  • Heated Leather-Trimmed Buckets w/60/40 Rear Seat -inc: 10-way power driver and passenger seat w/power lumbar adjust, driver seat memory, driver seat back map pocket
  • Manual Tilt/Telescoping Steering Column
  • Gauges -inc: Speedometer, Odometer, Engine Coolant Temp, Tachometer, Trip Odometer and Trip Computer
  • Power Rear Windows and Fixed 3rd Row Windows
  • SYNC Services Mobile Hotspot Internet Access
  • Leather/Metal-Look Steering Wheel
  • Front Cupholder
  • Rear Cupholder
  • 3 12V DC Power Outlets
  • Compass
  • Keypad
  • Proximity Key For Doors And Push Button Start
  • Remote Keyless Entry w/Integrated Key Transmitter, Illuminated Entry, Illuminated Ignition Switch and Panic Button
  • Remote Releases -Inc: Proximity Cargo Access
  • Garage Door Transmitter
  • Cruise Control w/Steering Wheel Controls
  • HVAC -inc: Underseat Ducts and Console Ducts
  • Voice Activated Dual Zone Front Automatic Air Conditioning
  • Illuminated Glove Box
  • Driver Foot Rest
  • Full Cloth Headliner
  • Interior Trim -inc: Piano Black Instrument Panel Insert, Metal-Look Door Panel Insert, Piano Black Console Insert and Chrome/Metal-Look Interior Accents
  • Leatherette Door Trim Insert
  • Leather/Metal-Look Gear Shifter Material
  • Driver And Passenger Visor Vanity Mirrors w/Driver And Passenger Illumination
  • Day-Night Auto-Dimming Rearview Mirror
  • Full Floor Console w/Covered Storage, Mini Overhead Console w/Storage, 3 12V DC Power Outlets and 1 AC Power Outlet
  • Fade-To-Off Interior Lighting
  • Front And Rear Map Lights
  • Full Carpet Floor Covering -inc: Carpet Front And Rear Floor Mats
  • Carpet Floor Trim
  • Cargo Area Concealed Storage
  • Trunk/Hatch Auto-Latch
  • Cargo Space Lights
  • Memory Settings -inc: Door Mirrors
  • FOB Controls -inc: Cargo Access and Remote Engine Start
  • Interior Concealed Storage, Driver / Passenger And Rear Door Bins, 2nd Row Underseat Storage and Audio Media Storage
  • Delayed Accessory Power
  • Power Door Locks w/Autolock Feature
  • Power 1st Row Windows w/Front And Rear 1-Touch Up/Down
  • Systems Monitor
  • Trip Computer
  • Analog Display
  • Outside Temp Gauge
  • Manual w/Tilt Front Head Restraints and Manual Adjustable Rear Head Restraints
  • Front Center Armrest and Rear Center Armrest
  • Securilock Anti-Theft Ignition (pats) Engine Immobilizer
  • Perimeter Alarm
  • Air Filtration
  • 3 12V DC Power Outlets and 1 AC Power Outlet
  • AdvanceTrac w/Roll Stability Control Electronic Stability Control (ESC) And Roll Stability Control (RSC)
  • ABS And Driveline Traction Control
  • Side Impact Beams
  • Dual Stage Driver And Passenger Seat-Mounted Side Airbags
  • Rear Parking Sensors
  • Rear Collision Warning
  • Low Tire Pressure Warning
  • Dual Stage Driver And Passenger Front Airbags
  • Safety Canopy System Curtain 1st And 2nd Row Airbags
  • Airbag Occupancy Sensor
  • Driver Knee Airbag
  • Mykey System -inc: Top Speed Limiter, Audio Volume Limiter, Early Low Fuel Warning, Programmable Sound Chimes and Beltminder w/Audio Mute
  • Rear Child Safety Locks
  • Outboard Front Lap And Shoulder Safety Belts -inc: Rear Center 3 Point, Height Adjusters and Pretensioners
  • Back-Up Camera
2016 Ford Escape Available Options
  • ENGINE: 1.6L ECOBOOST -inc: active grille shutters (99X) – Standard
  • ENGINE: 2.0L ECOBOOST (999)
  • TRANSMISSION: 6-SPEED AUTOMATIC W/SELECTSHIFT (446) – Standard
  • EQUIPMENT GROUP 300A (300A)
  • EQUIPMENT GROUP 301A -inc: Titanium Technology Package, BLIS w/Cross Traffic Alert, Blind Spot Information System replaces integrated blind spot mirrors, Bi-Xenon HID Headlamps, signature lighting, Rain-Sensing Wipers, Front only, Active Park Assist, (301A)
  • 3.51 AXLE RATIO (undefined) – Standard
  • 3.07 AXLE RATIO (undefined)
  • WHEELS: 18″ SPARKLE NICKEL PAINTED ALUMINUM (64C) – Standard
  • WHEELS: 19″ LUSTER NICKEL-PAINTED ALLOY -inc: Tires: P235/45R19 (641)
  • SUNSET (D7)
  • SHADOW BLACK (G1)
  • ELECTRIC SPICE (H8)
  • DEEP IMPACT BLUE (J4)
  • MAGNETIC (J7)
  • INGOT SILVER (UX)
  • RUBY RED METALLIC TINTED CLEARCOAT (RR)
  • WHITE PLATINUM METALLIC TRI-COAT (UG)
  • STANDARD PAINT (undefined)
  • MEDIUM LIGHT STONE, HEATED LEATHER-TRIMMED BUCKETS W/60/40 REAR SEAT (8L)
  • CHARCOAL BLACK, HEATED LEATHER-TRIMMED BUCKETS W/60/40 REAR SEAT (8B)
  • CALIFORNIA EMISSIONS SYSTEM -inc: Required code for California Emissions States registration (CA, CT, DE, MA, MD, ME, NJ, NY, OR, PA, RI, VT, WA), Optional code for Cross Border States dealer orders (AZ, DC, ID, NH, NV, OH, VA, WV) (422)
  • CALIFORNIA EMISSIONS SYSTEM NOT REQUIRED -inc: Dealers ordering a vehicle without a California Emissions System and which is being shipped to a California Emissions State dealer are also required to use Code 423 to attest either that the vehicle is not being registered in a California Emissions State or that Code 936 is applicable, NOTE: In Maine, Rhode Island and Vermont, dealers cannot order vehicles for customers in non California Emission State locations (except Public Service/Emergency Vehicles–936) (423)
  • CALIFORNIA PUBLIC SERVICE/EMERGENCY VEHICLE EXEMPT -inc: This exemption may only apply in certain states, Ordering dealer is responsible to contact the proper state authorities for clarification on qualifying exempted vehicles for registration, Only available on units sold for authorized public service or emergency service use (936)
  • DEALER ORDER FOR CALIFORNIA STATES REGISTRATION -inc: Federal Emissions State dealers ordering a California Emissions System (Code 422) are also required to use Code 93N to attest that the vehicle is to be registered in a California Emissions State, NOTE: it is a violation of Federal law for a Federal Emissions State dealer to sell a vehicle w/a California Emissions System for registration in a Federal Emissions State, unless the vehicle also meets EPA standards (i.e, 50-state emissions), Not Available For Stock Orders (93N)
  • ENGINE BLOCK HEATER (41H)
  • CLASS II TRAILER TOW -inc: trailer sway control (536)
  • GVWR: 4,840 LBS (undefined)
  • WHEEL LOCKING NUTS FOR ALLOY WHEELS (DLO) (87D)
  • TIRES: P235/45R19 (undefined)
  • PANORAMIC VISTA ROOF -inc: Right and left side LED lights replace the center dome light (43M)
  • SPLASH GUARDS (DEALER INSTALLED) (63S)
  • DAYTIME RUNNING LAMPS (DRL) -inc: Non-configurable (942)
  • ALL-WEATHER FLOOR MATS (50C)
  • CARGO AREA PROTECTOR (50Q)
  • ROOF CROSS BARS (61X)
  • INTERIOR CARGO COVER (85T)
  • VOICE-ACTIVATED TOUCHSCREEN NAVIGATION SYSTEM -inc: pinch-to-zoom capability, SiriusXM Traffic and Travel Link includes a 5-year prepaid subscription (582)
  • SMOKERS PACKAGE (94B)
  • EQUIPMENT GROUP 300A SAVINGS (undefined)
  • EQUIPMENT GROUP 301A SAVINGS (undefined)
  • SHIP THRU: AUTO TRUCK (31L)
  • SHIP THRU: MONROE TRUCK EQUIPMENT INC. (31N)
  • SHIP-THRU: PALFLEET TRUCK EQUIPMENT (31P)
  • SHIP-THRU: KNAPHEIDE TRUCK EQUIPMENT (31K)
  • SHIP THRU: MANNING (31M)
  • SHIP-THRU: ADRIAN STEEL (31V)
  • BUILT: LOUISVILLE PLANT (D9U)
2016 Ford Escape Consumer Information
  • Basic Years – 3
  • Basic Miles/km – 36,000
  • Drivetrain Years – 5
  • Drivetrain Miles/km – 60,000
  • Corrosion Years – 5
  • Corrosion Miles/km – Unlimited
  • Roadside Assistance Years – 5
  • Roadside Assistance Miles/km – 60,000
  • Overall Rating – * * * *
  • Overall Frontal Barrier Crash Rating – * * * *
  • Frontal Barrier Crash Rating Driver – * * * * (Male)
  • Frontal Barrier Crash Rating Passenger – * * * * (Female)
  • Overall Side Crash Rating – * * * * *
  • Side Barrier Rating – * * * * *
  • Side Barrier Rating Driver – * * * * * (Male)
  • Side Barrier Rating Passenger Rear Seat – * * * * * (Female)
  • Side Pole Rating Driver Front Seat – * * * * * (Female)
  • Male/Female Dummy Note – Male: Average sized adult male dummy in 35-MPH crash into fixed barrier. Rating is evaluation of injury to head, neck, chest, legs. Female: Small-sized adult female dummy in 35-mph crash into fixed barrier. Rating is evaluation of injury to head, neck, chest, legs.
  • Combined Side Rating Front Seat – * * * * *
  • Combined Side Rating Rear Seat – * * * * *
  • Rollover Rating – * * * *
  • Rollover Rating Dynamic Test Result – No Tip
  • Risk of Rollover – 18.5%
  • Rollover Note – Dynamic (moving) test results (Tip or No Tip) and measured rollover-related properties determine vehicle’s risk of rollover in single vehicle crash and its rollover rating. The Rollover Resistance Rating utilizes a “fishhook” maneuver which is a series of abrupt turns at varying speeds to see how “top-heavy” a vehicle is.
2016 Ford Escape Technical Specifications
  • Vehicle Name – Ford Escape
  • Body Style – Sport Utility
  • Drivetrain – Four Wheel Drive
  • Trans Order Code – 446
  • Trans Type – 6
  • Trans Description Cont. – Automatic w/OD
  • Trans Description Cont. Again –
  • First Gear Ratio (:1) – 4.58
  • Second Gear Ratio (:1) – 2.96
  • Third Gear Ratio (:1) – 1.91
  • Fourth Gear Ratio (:1) – 1.44
  • Fifth Gear Ratio (:1) – 1.00
  • Sixth Gear Ratio (:1) – 0.74
  • Reverse Ratio (:1) – 2.94
  • Final Drive Axle Ratio (:1) – 3.51, 3.07 (-NONAX0)
  • EPA Classification – Small SUV 4WD
  • Model Group –
  • Vehicle Segment –
  • Vehicle Type –
  • Passenger Capacity – 5
  • Passenger Volume – 98.1 ft³
  • Front Head Room – 39.9 in
  • Front Leg Room – 43.1 in
  • Front Shoulder Room – 56 in
  • Front Hip Room – 54.8 in
  • Second Head Room – 39 in
  • Second Leg Room – 36.8 in
  • Second Shoulder Room – 55.3 in
  • Second Hip Room – 52.4 in
  • Base Curb Weight – 3732 lbs (999), 3645 lbs
  • Fuel Economy Est-Combined – 25 MPG, 23 MPG (999&446)
  • EPA Fuel Economy Est – City – 22 MPG, 21 MPG (999&446)
  • EPA Fuel Economy Est – Hwy – 28 MPG (999&446), 29 MPG
  • Dead Weight Hitch – Max Trailer Wt. – 3500 lbs (536), 2000 lbs
  • Dead Weight Hitch – Max Tongue Wt. – 350 lbs (536), 200 lbs
  • Wt Distributing Hitch – Max Trailer Wt. – 3500 lbs (536), 2000 lbs
  • Wt Distributing Hitch – Max Tongue Wt. – 350 lbs (536), 200 lbs
  • Maximum Trailering Capacity – 3500 lbs (536), 2000 lbs
  • Engine Order Code – 999 (999&446), 999 (999), 99X
  • Engine Type – Intercooled Turbo Regular Unleaded I-4
  • Displacement – 2.0 L/122 (999&446), 2.0 L/122 (999), 1.6 L/98
  • Fuel System – Gasoline Direct Injection
  • SAE Net Horsepower @ RPM – 240 @ 5500 (999&446), 240 @ 5500 (999), 178 @ 5700
  • SAE Net Torque @ RPM – 270 @ 3000 (999&446), 270 @ 3000 (999), 184 @ 2500
  • Engine Displacement Units – 1.6 undefined, 1.6 undefined (99X), 2.0 undefined (999)
  • Engine Camshaft – DOHC undefined, DOHC undefined (99X), DOHC undefined (999)
  • Engine Block Type – aluminum undefined (999), aluminum undefined (99X)
  • Engine Cylinder Count – 4 undefined (999), 4 undefined (99X)
  • Engine Valve Count – 4 undefined (999), 4 undefined (99X)
  • Tons/yr of CO2 Emissions @ 15K mi/year – 7.1 (Est), 7.7 (Est) (999&446)
  • Suspension Type – Front – Strut
  • Suspension Type – Rear – Short And Long Arm
  • Suspension Type – Front (Cont.) – Strut
  • Suspension Type – Rear (Cont.) – Short And Long Arm
  • Front Tire Order Code –
  • Rear Tire Order Code –
  • Spare Tire Order Code –
  • Front Tire Size – P235/45HR19 (-NONTR0), P235/50HR18
  • Rear Tire Size – P235/45HR19 (-NONTR0), P235/50HR18
  • Spare Tire Size – Compact
  • Front Wheel Size – 19 X 8 in (641), 18 X 7.5 in
  • Rear Wheel Size – 19 X 8 in (641), 18 X 7.5 in
  • Spare Wheel Size – Compact in
  • Front Wheel Material – Aluminum
  • Rear Wheel Material – Aluminum
  • Spare Wheel Material – Steel
  • Steering Type – Rack-Pinion
  • Turning Diameter – Curb to Curb – 38.8 ft
  • Brake Type – 4-Wheel Disc
  • Brake ABS System – 4-Wheel
  • Disc – Front (Yes or ) – Yes
  • Disc – Rear (Yes or ) – Yes
  • Drum – Rear (Yes or ) –
  • Fuel Tank Capacity, Approx – 15.1 gal
  • Wheelbase – 105.9 in
  • Length, Overall – 178.1 in
  • Width, Max w/o mirrors – 72.4 in
  • Height, Overall – 66.3 in
  • Track Width, Front – 61.5 in
  • Track Width, Rear – 61.6 in
  • Min Ground Clearance – 7.9 in
  • Cargo Volume to Seat 1 – 67.8 ft³
  • Cargo Volume to Seat 2 – 34.3 ft³
  • Cargo Volume to Seat 3 – 34.3 ft³
